Reborn and rebuilt from the ground up, the All-New Mazda BT-50 is here. A whole new level of versatility and performance has been achieved through a relentless pursuit of challenging what is possible. Innovation greets you at every turn with more features at your disposal than ever before. Bold, balanced, stylish and capable, the Mazda BT-50 truly is the complete package.
The exterior design of the All-New Mazda BT-50 is the first true expression of Mazda’s Kodo Design language on a pick-up truck. The confident, planted stance projects strength, capability, and uncompromising quality. The new two-tone alloy wheel design gives BT-50 a unique and striking look. LED headlamps punctuate the front grille while sculpted side panels draw the eye to the bold rear presence.
Mazda BT-50 offers you the choice of two powerful, responsive and fuel-effcient diesel engines to perfectly match your individual needs wherever life or work takes you.
On-road or off, both powerplants: 3.0L turbocharged and 1.9L turbocharged – deliver the quiet, effortless performance that lets you confidently enjoy their unmatched versatility and dependability.
A 6-speed automatic contributes to BT-50’s excellent response and fuel economy. The rear differential lock instantaneously maximizes driveability over rough terrain.
SEE ALL THE FEATURES OF THE ALL NEW MAZDA BT-50 IN OUR PRODUCT BROCHURE
At Mazda, driving pleasure means more than just outstanding performance and handling. Because to us, feeling secure and well-protected is another essential component of enjoyable driving. And that is why BT-50 is equipped with the same leading-edge safety features demanded in passenger cars.
(MODEL ZR41 RAJ)
POWERTRAIN
In-line 4, DOHC,16 Valve, VGS Turbo Diesel,(RZ4E-TC)
Capacity - 1,898cc
Maximum Power - 148Hp/3,600rpm
Maximum Torque - 350Nm/1,800-2,600rpm
Drivetrain - 4WD
Fuel Type - Diesel
Fuel System - Common-rail, Electronic Direct Injection
Fuel Tank Capacity - 76 litres
CHASSIS
Brake Type - Ventilated Disc (Front)
Brake Type - Drum (Rear)
Suspension Type - Double Wishbones (Front)
Suspension Type - Leaf Springs (Rear)
Steering Type - Hydraulic Power Assist Steering
Wheel Type - Steel
Wheel Size - 16" x 6.5J
Tyre Size - 205/R16C
Wheel Type (Spare) - Full-size Steel
DIMENSIONS
Overall Length - 5,320mm
Overall Width - 1,810mm
Overall Height - 1,770mm
Wheelbase - 3,125mm
Ground Clearance - 220mm
Wading Depth - 400mm
Gross Vehicle Weight (GVW) - 2,800kg
Curb Weight - 1,800kg
Maximum Payload - 1,000kg
Cargo Deck(at floor):
Length - 2,345mm
Width - 1,120mm
Height - 465mm
EXTERIOR
Front LED Headlights
Auto Front Headlights On/Off Function
LED Front Fog Lights
Windshield Wipers with Rain Sensing & Variable Intermittent Function
INTERIOR
Steering Wheel Adjustment - Tilt & Telescopic
Radio with CD, MP3, AUX and USB
Seating Capacity - 2
SAFETY
SRS Airbags System
Anti-Lock Braking System (ABS)
Electronic Brake-Force Distribution (EBD)
Brake Assist (BA)
Electronic Stability Control (ESC)
Traction Control System (TCS)
Emergency Stop Signal (ESS)
Hill Launch Assist (HLA)
Hill Descent Control (HDC)
Engine-Immobilizer
(MODEL ZR48 RA7)
POWERTRAIN
In-line 4, DOHC,16 Valve, VGS Turbo Diesel, (RZ4E-TC)
Capacity - 1,898cc
Maximum Power - 148Hp/3,600rpm
Maximum Torque - 350Nm/1,800-2,600rpm
Drivetrain - 4WD
Fuel Type - Diesel
Fuel System - Common-rail, Electronic Direct Injection
Fuel Tank Capacity - 76 litres
CHASSIS
Brake Type - Ventilated Disc (Front)
Brake Type - Drum (Rear)
Suspension Type - Double Wishbones (Front)
Suspension Type - Leaf Springs (Rear)
Steering Type - Hydraulic Power Assist Steering
Wheel Type - Alloy
Wheel Size - 17" x 7.0J
Tyre Size - 255/65/R17
Wheel Type (Spare) - Full-size Alloy
DIMENSIONS
Overall Length - 5,280mm
Overall Width - 1,870mm
Overall Height - 1,785mm
Wheelbase - 3,125mm
Ground Clearance - 235mm
Wading Depth - 800mm
Gross Vehicle Weight (GVW) - 2,800kg
Curb Weight - 1,890kg
Maximum Payload - 910kg
Cargo Deck(at floor):
Length - 1,571mm
Width - 1,120mm
Height - 490mm
EXTERIOR
Front LED Headlights
Auto Front Headlights On/Off Function
LED Front Fog Lights
Windshield Wipers with Rain Sensing & Variable Intermittent Function
Parking Sensors - Rear
INTERIOR
Cruise Control
Reverse Camera with Guidelines
Steering Wheel with Audio & Bluetooth® Hands-Free Switches
7" Infotainment System with Voice Recognition
Apple CarPlay® & Android Auto™ Function*
Seating Capacity - 5
SAFETY
SRS Airbags System
Anti-Lock Braking System (ABS)
Electronic Brake-Force Distribution (EBD)
Brake Assist (BA)
Electronic Stability Control (ESC)
Traction Control System (TCS)
Emergency Stop Signal (ESS)
Hill Launch Assist (HLA)
Hill Descent Control (HDC)
Engine-Immobilizer with Anti-Theft System
Auto Door Lock
ADVANCED SAFETY TECHNOLOGIES
Blind Spot Monitoring (BSM)
Rear Cross Traffic Alert (RCTA)
*Android Auto™ will be available upon the official launch of service in Malaysia.
(MODEL ZR49 RAN)
POWERTRAIN
In-line 4, DOHC, 16 Valve, VGS Turbo Diesel, (RZ4E-TC)
Capacity - 1,898cc
Maximum Power - 148Hp/3,600rpm
Maximum Torque - 350Nm/1,800-2,600rpm
Drivetrain - 4WD
Fuel Type - Diesel
Fuel System - Common-rail, Electronic Direct Injection
Fuel Tank Capacity - 76 litres
CHASSIS
Brake Type - Ventilated Disc (Front)
Brake Type - Drum (Rear)
Suspension Type - Double Wishbones (Front)
Suspension Type - Leaf Springs (Rear)
Steering Type - Hydraulic Power Assist Steering
Wheel Type - Alloy
Wheel Size - 17" x 7.0J
Tyre Size - 255/65/R17
Wheel Type (Spare) - Full-size Alloy
DIMENSIONS
Overall Length - 5,280mm
Overall Width - 1,870mm
Overall Height - 1,785mm
Wheelbase - 3,125mm
Ground Clearance - 235mm
Wading Depth - 800mm
Gross Vehicle Weight (GVW) - 2,800kg
Curb Weight - 1,915kg
Maximum Payload - 885kg
Cargo Deck(at floor):
Length - 1,571mm
Width - 1,120mm
Height - 490mm
EXTERIOR
Front LED Headlights
Auto Front Headlights On/Off Function
LED Front Fog Lights
Windshield Wipers with Rain Sensing & Variable Intermittent Function
Parking Sensors - Rear
INTERIOR
Cruise Control
Reverse Camera with Guidelines
Steering Wheel with Audio & Bluetooth® Hands-Free Switches
7" Infotainment System with Voice Recognition
Apple CarPlay® & Android Auto™ Function*
Seating Capacity - 5
SAFETY
SRS Airbags System
Anti-Lock Braking System (ABS)
Electronic Brake-Force Distribution (EBD)
Brake Assist (BA)
Electronic Stability Control (ESC)
Traction Control System (TCS)
Emergency Stop Signal (ESS)
Hill Launch Assist (HLA)
Hill Descent Control (HDC)
Engine-Immobilizer with Anti-Theft System
Auto Door Lock
ADVANCED SAFETY TECHNOLOGIES
Blind Spot Monitoring (BSM)
Rear Cross Traffic Alert (RCTA)
*Android Auto™ will be available upon the official launch of service in Malaysia.
(MODEL ZR49 RAQ)
POWERTRAIN
In-line 4, DOHC,16 Valve, VGS Turbo Diesel,(RZ4E-TC)
Capacity - 1,898cc
Maximum Power - 148Hp/3,600rpm
Maximum Torque - 350Nm/1,800-2,600rpm
Drivetrain - 4WD
Fuel Type - Diesel
Fuel System - Common-rail, Electronic Direct Injection
Fuel Tank Capacity - 76 litres
CHASSIS
Brake Type - Ventilated Disc (Front)
Brake Type - Drum (Rear)
Suspension Type - Double Wishbones (Front)
Suspension Type - Leaf Springs (Rear)
Steering Type - Hydraulic Power Assist Steering
Wheel Type - Alloy
Wheel Size - 17" x 7.0J
Tyre Size - 255/65/R17
Wheel Type (Spare) - Full-size Alloy
DIMENSIONS
Overall Length - 5,280mm
Overall Width - 1,870mm
Overall Height - 1,805mm
Wheelbase - 3,125mm
Ground Clearance - 235mm
Wading Depth - 800mm
Gross Vehicle Weight (GVW) - 2,800kg
Curb Weight - 1,930kg
Maximum Payload - 870kg
Cargo Deck(at floor):
Length - 1,571mm
Width - 1,120mm
Height - 490mm
EXTERIOR
Front Bi-LED Headlights
Auto Front Headlights On/Off Function
Auto Front Headlights Leveling
LED Daytime Running Lights
LED Front Fog Lights
Windshield Wipers with Rain Sensing & Variable Intermittent Function
Door Entry - Advanced Keyless
Parking Sensors - Front & Rear
Roof Rails (100kg Limit)
Side Steps
INTERIOR
Engine Start / Stop Button
Cruise Control
Reverse Camera with Guidelines
Steering Wheel with Audio & Bluetooth® Hands-Free Switches
9" Infotainment System with Voice Recognition
Apple CarPlay® & Android Auto™ Function*
Seating Capacity - 5
SAFETY
SRS Airbags System
Anti-Lock Braking System (ABS)
Electronic Brake-Force Distribution (EBD)
Brake Assist (BA)
Electronic Stability Control (ESC)
Traction Control System (TCS)
Emergency Stop Signal (ESS)
Hill Launch Assist (HLA)
Hill Descent Control (HDC)
Engine-Immobilizer with Anti-Theft System
Auto Door Lock
Walk Away Lock
ADVANCED SAFETY TECHNOLOGIES
Blind Spot Monitoring (BSM)
Rear Cross Traffic Alert (RCTA)
*Android Auto™ will be available upon the official launch of service in Malaysia.
(MODEL ZR51 RBB)
POWERTRAIN
In-line 4, DOHC,16 Valve, VGS Turbo Diesel,(4JJ3-TCX)
Capacity - 2,999cc
Maximum Power - 188Hp/3,600rpm
Maximum Torque - 450Nm/1,600-2,600rpm
Drivetrain - 4WD
Fuel Type - Diesel
Fuel System - Common-rail, Electronic Direct Injection
Fuel Tank Capacity - 76 litres
CHASSIS
Brake Type - Ventilated Disc (Front)
Brake Type - Drum (Rear)
Suspension Type - Double Wishbones (Front)
Suspension Type - Leaf Springs (Rear)
Steering Type - Hydraulic Power Assist Steering
Wheel Type - Alloy
Wheel Size - 18" x 7.5J
Tyre Size - 265/60/R18
Wheel Type (Spare) - Full-size Alloy
DIMENSIONS
Overall Length - 5,280mm
Overall Width - 1,870mm
Overall Height - 1,810mm
Wheelbase - 3,125mm
Ground Clearance - 240mm
Wading Depth - 800mm
Gross Vehicle Weight (GVW) - 2,800kg
Curb Weight - 2,010kg
Maximum Payload - 790kg
Cargo Deck(at floor):
Length - 1,571mm
Width - 1,120mm
Height - 490mm
EXTERIOR
Front Bi-LED Headlights
Auto Front Headlights On/Off Function
Auto Front Headlights Leveling
LED Daytime Running Lights
LED Front Fog Lights
Windshield Wipers with Rain Sensing & Variable Intermittent Function
Door Entry - Advanced Keyless with Remote Start
Parking Sensors - Front & Rear
Roof Rails (100kg Limit)
Side Steps
INTERIOR
Engine Start / Stop Button
Reverse Camera with Guidelines
Steering Wheel with Audio & Bluetooth® Hands-Free Switches
9" Infotainment System with Voice Recognition
Apple CarPlay® & Android Auto™ Function*
Seating Capacity - 5
SAFETY
SRS Airbags System
Anti-Lock Braking System (ABS)
Electronic Brake-Force Distribution (EBD)
Brake Assist (BA)
Electronic Stability Control (ESC)
Traction Control System (TCS)
Multi Collision Brake
Emergency Stop Signal (ESS)
Hill Launch Assist (HLA)
Hill Descent Control (HDC)
Engine-Immobilizer with Anti-Theft System
Auto Door Lock
Walk Away Lock
ADVANCED SAFETY TECHNOLOGIES
Automatic High Beam (AHB)
Blind Spot Monitoring (BSM)
Rear Cross Traffic Alert (RCTA)
Lane Departure Warning System (LDWS)
Forward Collision Warning (FCW)
Auto Emergency Braking (AEB)
Adaptive Cruise Control (ACC)
*Android Auto™ will be available upon the official launch of service in Malaysia.
